| Model | MFA-5.1000 | |
| Class | D | |
| Number of the channels | 5 | |
| Frequency response | 10-20000 Hz | |
| Power RMS 4ohm (W) | 4 x 80 + 1 x 300 | |
| 4 x 120 + 1 x 500 | |
| 2 x 240 | |
| 1-4 channel High pass filter (Hz) | 50 – 12000 | |
| 1-4 channel Low pass filter (Hz) | 50 12000 | |
| 1-4 channel Crossover (db/oct) | 24 | |
| 5 channel Low pass filter (Hz) | 50 – 250 | |
| 5 channel Subsonic (Hz) | 10 – 55 | |
| 5 channel Crossover (db/oct) | 24 | |
| Minimum permissible load on the channel | 2 Ohm | |
| Minimum permissible load in a bridge connection | 4 Ohm | |
| LPF and HPF simultaneous operation | No | |
| Input SPL | 0.4 – 6V | |
| Input terminal | 4 Ga | |
| Output terminal | 8 Ga | |
| Working voltage | 9 – 15V | |
| Signal-to-noise ratio | ≥ 90 dB | |
| Size (WxLxH) | 5.98 x 10.69 x 2.15 inch |
