| Model | XAE-800.1D |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 22-400 Hz |
| 1 Ohm RMS Power (14.4 V) | 800 W |
| 2 Ohm RMS Power (14.4 V) | 500 W |
| 4 Ohm RMS Power (14.4 V) | 300 W |
| Minimum permissible load on the channel | 1 Ohm |
| Input SPL | 0.2 – 8 V |
| Low pass filter | 50-400 Hz |
| Subsonic filter | OFF / 25 Hz |
| Working voltage | 9 – 15 V |
| Signal-to-noise ratio | ≥ 85 dB |
| Size (WxLxH) | 220 x 200 x 58 mm |
| Gross weight | 2 kg |
